Triggered Coherence¶
Magnitude-squared coherence and coherency phase for configured channel pairs, accumulated across trials and split by condition.
Appears in the GUI processor list as Triggered Coherence. It needs the
FFTW runtime in the GUI's shared directory.
Work in progress — do not rely on this for results yet
It builds, loads and computes, and the estimator itself is tested numerically. Two things are known to be wrong or missing:
Screenshot placeholder — see Docs/assets/screenshots/README.md.
Coherence needs trials¶
A single trial has coherence 1 by construction. Coherence is only meaningful pooled over trials, and with few trials the estimate is badly biased upwards. The display shows the trial count and the significance threshold for that count; read both before reading the plot.
Three things exist here precisely because coherence is easy to over-read:
- the trial count, shown on every panel;
- the shift predictor, the trial-shifted null;
- PPC, pairwise phase consistency, which is unbiased by trial count.
The shift predictor¶
On by default. It accumulates a second estimate alongside the real one: channel A of each trial against channel B of the previous one. Anything that survives that shuffle is locked to the trigger rather than to an interaction between the channels — a shared evoked response, or a common reference. Without it, those look identical to a real interaction on the plot.
It costs a second accumulator per pair and holding the previous trial back. It is an analysis parameter — it cannot be reconstructed afterwards — so it is locked during acquisition.
A trial parked awaiting its commit message is kept out of the shift predictor: the null pairs consecutive kept trials.
PAIRS¶
Coherence is defined on pairs, and this window is the only way to create one. Reached
from the editor's CH PAIRS button.
Screenshot placeholder — see Docs/assets/screenshots/README.md.
Columns are name, the two channels, colour, resolution status and a delete button. Seed mode pairs one channel against every other selected one in a single step.
Channels are chosen from the selected channel list rather than by typing an index. Pairs whose channels later leave the selection stay configured and are shown as inactive.
Pair edits are not undoable
Removing a pair discards its accumulated cross-spectra, with no undo (#14). Trigger source edits are undoable; pair edits are not.
ANALYSIS¶
The same estimator settings as Triggered Power — Mode, the frequency axis, Morlet / Hann STFT, multitaper / Hann — plus one group of its own:
| Group | Parameters |
|---|---|
| Coherence controls | Shift predictor |
Triggered Coherence has no Max trials and no baseline or whitening groups. All of
ANALYSIS is locked during acquisition.
Defaults and ranges: Parameter reference → Spectral.
Canvas¶
Screenshot placeholder — see Docs/assets/screenshots/README.md.
| Control | Effect |
|---|---|
| Show | Coherence, Phase (of the coherency), Shift predictor (the trial-shifted null) or PPC. |
| Smooth t | Neighbouring time bins pooled into the estimate. 0–32, default 0. |
| Smooth f | Neighbouring frequency bins pooled into the estimate. 0–32, default 0. |
| Colour map | Viridis, Magma, Diverging or Greyscale. |
| Columns, Panel height | Grid layout. |
| CLEAR | Discards accumulated trials, keeps the conditions and the pairs. |
All display-time: they are applied when the display reads the accumulators and discard nothing.
The two smoothing controls¶
Wavelets give one estimate per trial, so with few trials the coherence estimate is badly biased upwards. Pooling neighbouring time-frequency bins into the cross-spectrum sums buys degrees of freedom at the cost of resolution, and is the main stabiliser in Spectrogram mode. In Spectrum mode the multitaper estimator already provides the degrees of freedom, and these matter much less.
There is no whitening control here: coherence is a normalised ratio, so a per-frequency gain cancels exactly.
Sessions¶
Not implemented, as for Triggered Power. There are no SAVE / LOAD buttons on this canvas.
Parameters¶
Full list with defaults, ranges and scope: Parameter reference → Spectral.
